iSCSI (uses IQN iSCSI qualified name) to identify Targets and Initiators, format as follows:
- date in year-month format
- reversed domain
- a unique org assgined name (ie: hostname)
Example: 2012-01.com.domain:iscsi1
Supported Storage Types
- date in year-month format
- reversed domain
- a unique org assgined name (ie: hostname)
Example: 2012-01.com.domain:iscsi1
Supported Storage Types
| Feature | Storage Repository Type |
Shared | Thin Provisioning |
Disk Resize | Multipathing | Fast Clone |
| Local Physical Disk | LVM | ✔ | ||||
| Local File System | EXT 3 | ✔ | ✔ | ✔ | ||
| HW iSCSI | LVMoHBA | ✔ | ✔ | ✔ | ||
| LVM over FC LUN | LVMoFC | ✔ | ✔ | NIC Bonding | ||
| Software iSCSI | LVMoISCSI | ✔ | ✔ | NIC Bonding | ||
| NFS | NFS | ✔ | ✔ | ✔ | NIC Bonding | ✔ |
| StorageLink* | ✔ | ✔ | ✔ | NIC Bonding |
Supported Capabilites
| Feature | Local Disk |
Fiber Channel |
HW iSCSIW |
SW iSCSI | NFS |
| Store VM | ✔ | ✔ | ✔ | ✔ | ✔ |
| Auto Placement | ✔ | ✔ | ✔ | ✔ | |
| XenMotion | ✔ | ✔ | ✔ | ✔ | |
| Resize Disks | ✔ | ✔ | ✔ | ✔ | ✔ |
| Fast Clone | ✔ | ✔ | |||
| Thin Provisioning | ✔ |
StorageLink Storage Repository
- A set of APIs which interface directly with storage arrays
- Offloads intensive tasks: Provisioning, Snapshot, Cloning
- Can co-exist with non StorageLink repository on the same array
- The features are based on the capabilities of the storage array
Storage Repository Removal Options
- Detach - to attach later (disconnect for later reconnection)
- Forget - entire configuration for the repo is "forgotten" but the data remains
- Destroy - like a delete button, everything is gone
- Detach - to attach later (disconnect for later reconnection)
- Forget - entire configuration for the repo is "forgotten" but the data remains
- Destroy - like a delete button, everything is gone
